Philips 107E7 - Page 52

17” CDT Color Monitor 107E7
52
IC801
NT6812
1
2
3
4
5
6
7
8
9
10
11
12 13
14
15
16
17
18
19
20
21
22
23
24
VBLK
CAP_A
VDD_1
GND_A
B_IN
R_IN
G_IN
GND-PLL
VCO
5V_PLL
SDA
SCL CAP_D
DA3
DA2
DA1
GND_2
VDD_2
G_OUT
R_OUT
B_OUT
ABL
CLAMP
HBLK
