17” CDT Color Monitor 107E7
69
1 Red video
2 Green video
3 Blue video
4 GND
5 Self test
6 Red GND
7 Green GND
8 Blue GND
9 +5V (Supply from PC for DDC circuit)
10 Sync GND
11 GND
12 DDC serial data
13 H-sync
14 V-sync
15 DDC serial clock
• H-sync line impedance must be within 50 ~ 70Ω (TDR measurement).
• V-sync line impedance should be within 40 ~ 70Ω (TDR measurement).
•
RGB signal lines must be 75Ω ± 5% coaxial.
•
R, G, B coaxial shield must connect to D-Sub metal shell.
3. Front Of Screen Performance
3.1 CRT characteristics
Vendor
LPD CPT
CRT Type Number
Screen & Mask
Curved screen & Shadow mask Curved screen & Shadow mask
Screen Diagonal Size
444mm 444mmm
Phosphor Area
325mm x 244mm 325mm x 244mm
VIS (front bezel opening)
Neck size
29.1mm 29.1mm
Deflection Angle
90º 90º
Yoke impedance
LH: xxx uH
LV: xxx mH
RH: xxx Ω
RV: xxx Ω
LH: xxx uH
LV: xxx mH
RH: xxx Ω
RV: xxx Ω
Phosphor Dot Pitch
0.27mm 0.27mm
Phosphor Type
P22, medium short persistence P22, medium short persistence
Light Transmission rate
Surface Treatment
Anti glare/Anti static Anti glare/Anti static
Surface Resistance
CRT net Weight
3.2 Display image / Geometric distortions
