17” CDT Color Monitor 107E7
68
SIZE
POSITION ADJUST VERTICAL
SIZE
PINCUSHION ADJUST SIDE CURVE
BALANCED
TRAPEZOID ADJUST SIDE ANGLES
PARALLELOGRAM
ADJUST SHAPE
ROTATE IMAGE ROTATE
9300K FOR GENERAL USE
6500K FOR IMAGE MANAGEMENT
sRGB
USER PRESET
RED
GREEN
ADJUST COLOR
BLUE
NO RESET TO FACTORY
SETTING
YES
HORIZONTAL ADJUST MOIRE
VERTICAL
EXTRA CONTROLS
DEGAUSS
CLOSE MAIN CONTROLS
•
OSD lock - Lock all OSD by holding down “MENU” key for 15 seconds.
2.7.3 LED indicator
•
Normal on - Green.
• Active off - Green Blinking (1sec on / 1sec off).
• Switch off - Blank.
2.7.4 Monitor status information
•
Self-test feature - “CHECK SIGNAL CABLE” message appears when video cable
is disconnected.
• Out of scan range - “FREQUENCY IS OUT OF RANGE” appears when input H-sync
or V-sync out of range.
• Resolution & H/V input - Shown in OSD menu “EXTRA CONTROLS”.
2.7.5 Power connector
•
AC socket 3-pin IEC-320-C13, at rear side.
2.7.6 Video input connector/Video cable
• 1.5m non-detachable fly-in video cable with D-Sub 15 pin male blue connector, pin assignment of D-Sub:
Pin
Function
