JACK PANEL DEFINITIONS
JP9000 JP9202 JP9403 JP9406 JP9410 JP9610
RF INPUT/ANTENNA 75 OHM 75 OHM 75 OHM 75 OHM 75 OHM 75 OHM
JACKS QUANTITY 0 2 3 7 10 10
VIDEO INPUT 1 1 1 2 2
AUDIO INPUT 1 1 L-R 2 (L-R) 2 (L-R)
(1 Rear, 1 Side)
HEADPHONE FRONT FRONT FRONT
VIDEO OUTPUT 1 1 1
AUDIO OUTPUT L-R (FIXED)
L-R (FIXED)
* Only one set of audio output jacks, menu selectable, switchable between fixed and variable output.
GLOSSARY OF TERMS, ACRONYMS, AND ABBREVIATIONS
2CS Two Channel Stereo
AFC Automatic Frequency Control
AFT Automatic Fine Tuning
AP Asia Pacific
ATS Automatic Tuning System
AV External Audio/Video
AVL Automatic Volume Level control
BTSC Broadcast Television Standard Committee (TV stereo)
CBA Circuit Board Assembly (PCB)
CC Closed Captioning
CSM Customer Service Mode
CVBS Color Video Blanking Sync
DNR Dynamic Noise Reduction
EEPROM Electrical Erasable Programmable Read-Only Memory
Error Buffer Register that keeps track of errors that occur and stores error codes
Error Code A numerical value used to indicate a failure in the television
EU Europe
EXT External audio/video input
FM Frequency Modulation
I²C Inter IC bus, 2-wire bi-directional (SCL/SDA)
ID Identification
IDENT Horizontal coincidence signal, transmitter identification
IF Intermediate Frequency
IN ITT sound IC with NICAM function
IT ITT sound IC without NICAM function
LATAM Latin America
LED Light Emitting Diode
Local Keyboard The buttons (usually volume up, volume down, channel up, and channel down) located on
the front of the television set
MA Mono All; single mono carrier receiver
NICAM Near Instantaneous Companding Audio Multiplex; Digital Sound System
NR Noise Reduction
