26
Meridian 3
6.4 IR Board (715G5459R01000004S)
Remark: Parts position can be searched by using FIND function in PDF.
IR_RX
PS_OUTPUT
VCC_IN
IR_RX
R/A: 081G 15W 1 EL
V/T: 081G 63W 2 GP
REVERSE: 081G 14 31 EL
FFC R/A: 311GF100C06ADH
FFC V/T: 311GF100D06ACJ
FFC CABLE: 089G 76J 6 3
WIRE V/T: 033G8032 6F S HR
FFC R/A: 311GF100C12ADH
FFC V/T: 311GF100D12ACJ
FFC CABLE: 395G076J12NM01
WIRE V/T: 033G803212F S HR
R313
1K
C311
100N 16V
C318
100N 16V
C316
100N 16V
C312
100N 16V
C317
100N 16V
R312
100K1/16W
LED_VCC
PS_OUTPUT
C315
100N 16V
1
2
3
4
5
6
78
CN311
CONN
VCC_KB
R323
10K
I2C_SDA
PS_ON
1 2
ZD312NC/UDZSNP5.6B
1
2
3
4
5
6
7
8
9
10
11
12
CN312
CONN
PS_DISTANCE
I2C_SCL
SM_INT#
R315
100K1/16W
C314 22UF 16V
R320
100OHM
R316
100 OHM 1/8W
R311
1K
1OUT
1
1IN-
2
1IN+
3
GND
4
2IN+
5
2IN-
6
2OUT
7
VCC+
8
U311
AS358MTR-E1
R317
33 OHM 1/8W
VDD
1
GP5/T1CKI/P1A*/OSC1/CLKIN
2
GP4/AN3/CIN1-/T1G/P1B*/OSC2/CLKOUT
3
GP3/T1G*/MCLR/VPP
4
GP2/AN2/T0CKI/INT/COUT/CCP1/P1A
5
GP1/AN1/CIN0-/VREF/ICSPCLK
6
GP0/AN0/CIN+/P1B/ICSPDAT
7
VSS
8
U313
PIC12F615-I/SN
C313 22UF 16V
1 2
ZD313NC/UDZSNP5.6B
R319
1K
Q313
AO3401A
C320
100N 16V
R324
10K
R322
10K
C319
100N 16V
Q312
SST2222A
R314
100K1/16W
VOUT
1
GND
2
VCC
3
HAND1
4
HAND2
5
U312
IRM-3638M3S28
R321
1K
12
LED311
A8824B/IR204C-A
12
LED312
LED
1 2
ZD311NC/UDZSNP5.6B
R318
33 OHM 1/8W
Q311
SST2222A
VCC
VCCVCC
VCC_IN
VCC
VCC
VCC
VCC_IN
PS_ON
VCC_KB
LED_White
I2C_SCL
I2C_SDA
PS_ON
PS_OUTPUT
PS_DISTANCE
LED_VCC
PS_DISTANCE
LED_white
SM_INT#
POWER SENSOR_LED
To Next Page
