1 CONTENTS
2 FOREWORD
This specification describes a 22" FHD multi-scan color TFT LCD monitor with maximum resolution up to
1680x1050 /75Hz non-interlaced. This model uses 250nits panel.All optical characteristics are determined
according to panel specification after warming up longer than 30 minutes.
3 PRODUCT PROFILE
3.1 EDID header
1 User visible strings on .inf file Philips 220BLP (22inch Wide LCD MONITOR 220B4LP)
2 Manufacturer ID ( EDID data) PHL
3 Product ID, "xxxx" 4 codes MSB(byte 12): 08
ʳ ʳ LSB (byte 11): BF
4 maximum resolution 1680x1050
5 Horizontal Frequency Range 30~83 KHz
6 Vertical Frequency Range 56~76Hz
LCD
Suppliers to offer panel specifications.
Panel incoming specification: Follow Philips’ specification.
CMI
Type NR. : M220ZGE L20 CMI
Resolution : 1680 x 1050 (WSXGA+)
Outside dimensions : 473.76(H) x 296.1(V)
Pitch (mm) : 0.0883mm(RGB) x 0.265(V)mm
Color pixel arrangement : RGB vertical stripe
Display surface : Haze 25% Hard coating (3H)
Color depth : 16.7M (6 bit Hi-FRC)
Backlight : LED
Active area (W x H) : 493.2(H) x 319.6(V) mm
View angle (CR=10) : =170 for Right/Left (Typ)
: =160 for Up/Down (Typ)
Contrast ratio : 1000:1 (Typ)
White luminance : 250(Typ.)
Color gamut : >=72%
Gate IC : N/A
Source IC : N/A
Response time : Tr + Tf <=5 ms (Typ)
Vertical frequency range : 56~75Hz
3.2 Scanning frequencies
Hor. : 30 – 83 K Hz
Ver. : 56 - 76 Hz
Video dot rate: < 210 MHz for VGA and < 170 MHz for DVI, warning message must be
displayed while over 165 MHz (supplier to provide accurate scaler bandwidth number)
Power input: 90-264 V AC, 50/60 r 2 Hz
Power consumption:
On mode: :<58W (max.),
:31W (typ.) W/O USB,AUDIO
EPA 5.0 spec. : Watt. (typ.)
SmartImage ECO mode: : 50% Max power consumption
