70
Meridian 3
2. Perfect FOS after auto adjustment.
User mode
1. Can save those timing that not in Preset mode and can be showed (not over scaler or
Panel spec.)
2. It needs to reserve the 10 timings space in memory size.
Mode storing capacity
Factory preset modes: 15
preset modes : 41
User modes : 10
Factory preset modes ( D-sub15 modes)
1. Factory modes and preset modes are defined in the enclosed timing table file
06HULHV
7LPLQJWDEOHOLVW
2. Video timing mode (internal firmware support) , (for DP model)
60Hz: 480p/720p/1080i/1080p
50Hz: 576p/720p/1080i/1080p
Software control functions via OSD / control adjustable functions:
Please refer to following Hudson9 OSD definitions, if any deviation, then refer to PVT Exit sample.
ITEM
1 OSD DEFINITIONS
026'%XWWRQ
GHILQLWLRQB
Reset -
No: Exit
Yes: Auto adjustment for
displaying timing mode and
recall factory preset
2 OSD LANGUAGES
26'B6WULQJB0B
[OV[
8 LANGUAGES
3 OSD TREE
26'%XWWRQ
GHILQLWLRQB
4 POWER ON LOGO
[BQHZEPS
Power On Logo: Power On
Æ Show up Philips logo 3
seconds
Æ Change to input signal.
This picture is reference only.
The official drawing will send
out by PM.
5 Audio Selection Stand-alone – On:
Isolate video and audio control
input
Stand-alone – Off:
Integrate video and audio control
input
Mute – On: Turn off audio
Mute – Off: Turn on audio
4.4Horizontal scanning
Sync polarity : Positive or Negative
Scanning frequency : 30 – 83 K Hz
