Meridian 3
HS3 Q90G6084 3 HEAT SINK
U903 056G 158 10 T DC/DC AS431AZTR-E1 150MA 40V TO-92
U903 056G 158504AME IC AME431BAJATB25Z AME
Q904 057G 530503 T 2SD1207T
Q904 057G 761 16 TRA KTD1028 KEC
R915 061G 17222052T TZ RST CFR 22R 5% 1/4W
R915 061G 17222052T XZ RST CFR 22 OHM +-5% 1/4W XIANZHENG
R906 061G152M10452T HX RST MOF 100K 5% 2WS
R906 061G152M10452T SY RST MOFR 100KOHM +-5% 2WS FUTABA
R904 061G152M25152T HX RST MOF 250R 5% 2W
R904 061G152M25152T SY RST MOF 250R 5% 2W
R924 061G152M47852T SY RST MOFR 0.47 OHM +-5% 2WS FUTABA
C911 065G 2K152 2T6213 CAP CER 1.5NF 10% 2KV Y5P
C911 065G 2K152 2T6921 CAP CER 1500PF K 2KV Y5P
C816 065G517K102 2T6921 CAP CER 1000PF K 500V Y5P
C920 067G 2046812KT CAP CS 680UF 20% 10V 8*11 3900MA GP1A6
C920 067G 2046812LT CAP CS 680UF 20% 10V 8*11.5 2000 HR 3900
C809 067G 4153309KT EC 33UF 20% 100V 8*12 ED
C801 067G215D3314KT EC 330UF 20% 25V 10*12 ED
C922 067G215S4713KT EC 470UF 20% 16V 10*13 ED 4000 HR 1030MA
C922 067G215S4713LT EC 470UF 20% 16V 10*12.5 4000 HR
C913 067G215Y4707KT EC 47UF 20% 50V 6.3*11MM EG
C913 067G215Y4707LT LOW ESR EC 47UF 50V M 6.3*11MM
FB902 071G 55 29 FERRITE BEAD
F901 084G 56 4 B FUSE 4A 250V
F901 084G 56 4W FUSE 4A 250V
ZD901 093G 3916352T ZD TZX22B
ZD901 093G 3916826T ZENER MTZJ T-77 22B 22V 0.5W DO-34
D903 093G 6026T52T CTIFIER DIODE FR107
D907 093G 6451652T 1N4148
D907 093G 6452452T SWITCHING 1N4148-B4006 0.2A 100V DO-35
D904 093G110050152T DIODE PR1007 1A/1000V 500NS DO-41
C801 367G215X3314LT EC 330UF 20% 25V 10*12.5
Note:
Take the 246V5LAB/00 BOM for example, the parts information listed below are for reference only, and are
subject to change without notice. Please go to http://cs.tpv.com.cn/hello1.asp
for the latest information
Item location PCM Codes Description
Remark
1
FQ105 A34G3175AFLB2B0100 BEZEL
2
FQ411 A33G144400201C0100 LENS
3
E750 750GBU240H1D23N000 LCD M240HW01 VD0A XM AUO
4
FQ003 PLPCCE514UQGZ POWER BOARD ASSY
5
FQ124 Q15G13953010FJ MAINFRAME
6
FQ004 KEPCCPHQ1 KEY BOARD ASSY
7
FQ144 A33G1366ANG 1L0100 KEY
8
FQ108 A34G3178AFL01B0100 STAND_BUTTON
9
FQ109 A34G3179AFL01B0100 BASE
