86
Meridian 3
Pull-up Resistor: 2.7KΩ±10%
Leakage Current in standby/off : < 1.8uA
Maximum Capacitance: 100pF
3). Audio in ( option , refer to Quick specification table)
Input signal: 1Vrms
Loudspeaker: stereo of RMS Power
Frequency range: (WAIT FOR SUPPLIER INPUT)
Headphone connection will mute speaker
7). HDMI audio out (headphone): (option, refer to Quick specification table)
Stereo, > 50mVrms for headphone of 32
Interface
D-Sub Cable
Length : Please refer to M3 cable bundle summary file
Fix with monitor when packing, with transplant pin protective cover.
Connector type : D-Sub male with DDC2B pin assignments.
Blue connector thumb-operated jack screws
Pin assignments:
PIN No. SIGNAL
1 Red
2 Green/ SOG
3 Blue
4 Sense (GND)
5 Cable Detect (GND)
6 Red GND
7 Green GND
8 Blue GND
9 DDC +3.3V or +5V
10 Logic GND
11 Sense (GND)
12 Bi-directional data
13 H/H+V sync
14 V-sync
15 Data clock
DVI Cable
The input signals are applied to the display through DVI-D cable.
Length : Please refer to cable bundle summary file
Connector type : DVI-D male with DDC-2B pin assignments
White connector thumb-operated jackscrews
With transplant pin protective cover.
