88
Meridian 3
3.2.4 3.5mm Audio Jack cable
Length : Please refer to cable bundle summary file
Connector type : 3.5mm stereo audio jack (TRS) connector
Timing requirement
Factory Preset mode definition:
1. Perfect FOS while presenting those timings.
2. Will specify those timing in User's Manual
Preset mode definition:
1. Need to support those timings.
2. Perfect FOS after auto adjustment.
User mode
1. Can save those timing that not in Preset mode and can be showed (not over scaler or
Panel spec.)
2. It needs to reserve the 10 timings space in memory size.
Mode storing capacity
Factory preset modes : Refer to Timing table
preset modes : Refer to Timing table
User modes : Refer to Timing table
Timing pixel clock over H/W limitation do not support.
1. Factory preset modes and preset modes are defined in the enclosed timing table file
246V5 LCD MTR
Product Identification
OSD/Keypad functions
ITEM
1 OSD/keypad definition
MMD OSD_Function
definition _FW SP
246V5 LCD MTR
Product Identification
Reset -
No: Exit
Yes: Auto adjustment for
displaying timing mode and
recall factory preset
2 OSD Translation
246V5 OSD
Translation V01_201
English, Spanish, French,
German, Italian,
Portuguese, Russian, S.
Chinese, Turkish, Dutch,
Swedish, Finnish, Polish,
Czech, Korean, T. Chinese,
Japanese, Hungarian,
Greek, Ukrainian, Brazil
Portuguese(21)
3 Power On logo
Philips_Logo_1920x
Power On Logo: Power On
Show up Philips logo 3
seconds
Change to input signal.
This picture is reference
only. The official drawing will
send out by PM.
