Alignments
EN 49Q522.1HE LA 6.
2009-Dec-04
6.7 Total Overview SAM modes
Table 6-4 SAM mode overview (usage is model dependent)
Main Menu Sub-menu 1 Sub-menu 2 Sub-menu 3 Description
Hardware Info A. SW VERSION e.g. “Q5492_1.26.15.0” Display TV & Standby SW version and CTN serial
number.
B. Standby processor version e.g. “STDBY_88.68.0.0”
C. Production code e.g. “See type plate”
Operation hours Displays the accumulated total of operation hours.TV
switched “on/off” & every 0.5 hours is increase one
Errors Displayed the most recent errors.
Reset error buffer Start now Clears all content in the error buffer.
Alignment Tuner AGC RF-AGC Take over point adjustment (AGC default
value is 80)
White point Colour temperature Normal 3 different modes of colour temperature can be
selected
Warn
Cool
White point red LCD White Point Alignment. For values,
see Table 6-2 Tint settings.
White point green
White point blue
Red black level offset
Green black level offset
Dealer options Personal options Picture mute Off/On Select Picture mute On/Off. Picture is muted / not
muted in case no input signal is detected at input
connectors.
Virgin mode Off/On Select Virgin mode On/Off. TV starts up / does not
start up (once) with a language selection menu after
the mains switch is turned “on” for the first time (virgin
mode)
E-sticker Off/On Select E-sticker On/Off (USPs on-screen)
Auto store mode None
PDC/VPS
TXT page
PDC/VPS/TXT
Options Digital broadcast DVB Off/On Select DVB On/Off
DVB - T installation Off/On or Country dependent Select DVB T installation On/Off or by country
DVB - T light Off/On Select DVB T light On/Off
DVB - C Off/On Select DVB C On/Off
DVB - C installation Off/On or Country dependent Select DVB C installation On/Off or by country
Over the air download Off/On or Country dependent Select Over the air download On/Off or by country
8 days EPG Off/On Select 8 day EPG On/Off
Digital features USB Off/On Select USB On/Off
Ethernet Off/On Select Ethernet On/Off
Wi-Fi Off/On Select Wi-Fi On/Off
DLNA Off/On Select DLNA On/Off
On-line service Off On-line service is Off
PTP (Picture Transfer Protocol) Off/On Select PTP On/Off
Update assistant Off/On Select Update assistant On/Off
Internet software update Off Internet software update is Off
Data EPG Off/On Select EPG On/Off
TvTv EPG Off/On Select TvTv EPG On/Off
Display Screen 201 / LCD LPL WUE SBA1 37" Displayed the panel code & type model.
Dimming backlight Off/On Select Dimming Backlight On/Off
LightGuide Off/On Select LightGuide On/Off
Display fans Not present/Present Select Display fans Present/Not present.
Temperature sensor Sensor present in display (only for
21:9)
N.A.
Temperature LUT 0 N.A
E-box & monitor Off/On Select E-box & monitor On/Off
Video reproduction Picture processing None/PNX5100 Select Picture processing None/PNX5100 (Q549.xE
chassis).
MOP local contrast Off/On Select MOP local contrast On/Off
Light sensor Off/On Select Light sensor On/Off
Light sensor type 0/1/2/3 Select Light sensor type form 0 to 3 (for difference
styling).
Pixel Plus type Pixel Plus HD Select type of picture improvement.
Perfect Pixel HD
Pixel Precise HD
Pixel Plus Off/On Select Pixel Plus On/Off
Ambilight Off/Mono/Stereo/Triple/Quad/Pixel
ated quad
Select type of Ambilight modules use.
Ambilight technology CCFL/LED Select Ambilight technology.
Ambilight driver Pacific 3/MOP/DFI Select Ambilight driver.
Pacific 3 Not present/Present Select Pacific 3 presence.
MOP Not present/Present Select MOP presence.
MOP ambilight Off/On Select MOP ambilight On/Off
