Philips 48OLED806/12 - Page 83

9-9-2 Ambilight 11-LED
C012
100N16V
R060 22R 1/16W 5%
R061 22R 1/16W 5%
R062 22R 1/16W 5%
R063 22R 1/16W 5%
PWM2-R2
+12V
PWM2-B2
PWM2-G2
R025 560R
R026 560R
R027 560R
R028 560R
+12V
PWM2-G1 2
PWM2-B1 2
PWM2-R1 2
+12V
R064 180R
R065 180R
R066 180R
R067 180R
PWM2-R3
PWM2-B3
PWM2-G3
R029 560R
R030 560R
R031 560R
R032 560R
PWM2-B4 2
+12V
PWM2-R4 2
PWM2-G4 2
C013
NC/100NF 50V
C015
NC/100NF 50V
C011
NC/100NF 50V
PWM2-R4
PWM2-B4
PWM2-G4
C009
NC/100NF 50V
R033 560R
R034 560R
R035 560R
R036 560R
R044 22R 1/16W 5%
R045 22R 1/16W 5%
R046 22R 1/16W 5%
R047 22R 1/16W 5%
PWM2-R1
PWM2-G1
PWM2-B1
R021 560R
R022 560R
R023 560R
R024 560R
R040 22R 1/16W 5%
R041 22R 1/16W 5%
R042 22R 1/16W 5%
PWM2-B2 2
R043 22R 1/16W 5%
PWM2-G2 2
PWM2-R2 2
R ed B l ueGr e en
D001
LTW-X45T-P2H
1
2
3
4
5
6
7
8
R ed B l ueGr e en
D002
LTW-X45T-P2H
1
2
3
4
5
6
7
8
R ed B l ueGr e en
D003
LTW-X45T-P2H
1
2
3
4
5
6
7
8
PWM2-G3 2
PWM2-B3 2
PWM2-R3 2
Re d B l ueGr ee n
D004
LTW-X45T-P2H
1
2
3
4
5
6
7
8
Re d B l ueGr ee n
D005
LTW-X45T-P2H
1
2
3
4
5
6
7
8
R ed B l ueGr e en
D006
LTW-X45T-P2H
1
2
3
4
5
6
7
8
R ed B l ueGr e en
D007
LTW-X45T-P2H
1
2
3
4
5
6
7
8
R ed B l ueGr e en
D008
LTW-X45T-P2H
1
2
3
4
5
6
7
8
Re d B lu eGr ee n
D009
LTW-X45T-P2H
1
2
3
4
5
6
7
8
Re d B lu eGr ee n
D010
LTW-X45T-P2H
1
2
3
4
5
6
7
8
C008
100N16V
C010
100N16V
C014
100N16V
Re d B lu eGr ee n
D011
LTW-X45T-P2H
1
2
3
4
5
6
7
8
