Philips 65PUT6162 - Page 8

3.2.3 Rear Cover
Warning: Disconnect the mains power cord before removing the rear cover.
1. Remove fixation screws [2] and [3] that secure the back cover.(6102 series)
Remove fixation screws [2] and [3] that secure the back cover. Unplug the connector [4].(6162 series)
2. Gently lift the rear cover from the TV. Make sure that wires and cables are not damaged while lifting the rear cover from the set.
(6102 series)
2
2
2
2
2
2
2
2
3
3
2
2
2
2
2
2
2
2
2
2 2
2
2
