(6162 series)
3.2.3 Keyboard Control Unit
1. Release the connector from the SSB Board.
Caution: be careful, the Keyboard is catch on the Back cover, please be careful to avoid damage the fragile connectors!
2. Remove all the fixation screws[1] and the connector [2] from the keyboard control panel and take it out from the Back cover.
When defective, replace the whole unit.
