11 - 1
ELECTRICAL PARTSLIST
CD / CONTROL BOARD TUNER BOARD
- MISCELLANEOUS - - MISCELLANEOUS -
LCD401 9965 000 17776 LCD DISPLAY 0237 OTR-P1 SW301 9965 000 17784 SLIDE SWITCH 4P2T
R456 9965 000 17773 FUSIBLE RES 0.47R 1/2W VC301 9965 000 17787 AM/FM PVC
SW201 4822 276 13443 TACT SWITCH 9965 000 17271 ANTENNA BAR 5X13X55
SW202 4822 276 13443 TACT SWITCH
SW203 4822 276 13443 TACT SWITCH
- COILS AND FILTERS -
SW204 4822 276 13443 TACT SWITCH
SW205 4822 276 13443 TACT SWITCH F301 9965 000 17777 AM CER. FILTER SFU468B
9965 000 17774 FFC 16P 140MM F302 9965 000 17778 FM CER. FILTER LT10.7MJ
9965 000 17775 CD DOOR SWITCH F303 9965 000 17779 FM CER. FILTER JT10.7MG
L301 9965 000 17781 MW ANT. COIL 93:30T
L302 9965 000 17782 FM COIL 4-1/2T
- COILS AND FILTERS -
L303 9965 000 17782 FM COIL 4-1/2T
L401 9965 000 17770 CHOKE COIL 10UH L304 9965 000 17783 BOBBIN COIL 3-1/2T
X401 9965 000 16781 CER.RES CRA16.93M T301 9965 000 17785 MW OSC COIL
T302 9965 000 17786 AM IFT YELLOW
- DIODES - - IC & TRANSISTORS -
D414 9965 000 17767 ZENER DIODE 9V1 1/2W IC301 9965 000 17780 TA2111N
- IC & TRANSISTORS -
RECORDER BOARD
IC401 9965 000 17768 IC LA9242M
IC402 9965 000 17769 IC LC78601RE-8615D - MISCELLANEOUS -
IC403 4822 209 15786 LA6541D
Q401 9965 000 17771 TRANS 2SA608NG 1707 4822 277 11504 PUSH SWITCH 6P2T
Q402 4822 130 42615 BC817-40 5701 4822 157 10371 BIAS OSC COIL
Q405 9965 000 17772 TRANS 2SB764E-SSH
Q406 5322 130 60123 BC807-40 - DIODES -
Q407 4822 130 42615 BC817-40
Q408 5322 130 60123 BC807-40
6704 4822 130 30621 1N4148
Q413 5322 130 41843 2SC2655Y
- IC & TRANSISTORS -
7702 4822 130 40981 BC337-25
7705 4822 209 17498 AN7323
