ELECTRICAL PARTSLIST - TUNER BOARD
- COILS & FILTERS -
5104 2422 535 91074 ANT FM046-B 185µH
5104 2422 536 00364 ANT FM065 190µH
5109 4822 242 70665 SFE10,7MS3-A
5110 4822 242 70665 SFE10,7MS3-A
5111 2422 549 44023 IND VAR 7MM 7PY 450KHZ
5112 4822 157 70302 F7MCS-12216N
5114 4822 157 70302 F7MCS-12216N
5119 4822 157 11443 2,4µH 10,7MHZ
5121 4822 242 10261 T6252F00 (75KHZ)
5123 2422 549 44108 IND VAR 7MM 7PY 796KHZ
5130 4822 157 11843 MD7B-01F
5131 4822 157 11843 MD7B-01F
- DIODES -
6103 5322 130 34337 BAV99
6105 4822 130 83075 HN1V02H-B
6120 4822 130 83757 MCL4148
6130 4822 130 82833 1SV228
6131 4822 130 82833 1SV228
6181 5322 130 34337 BAV99
6182 4822 130 83757 MCL4148
6183 9340 386 90115 BZX284-C11
- IC & TRANSISTORS -
7101 4822 209 90924 TEA5757H/V1
7102 4822 130 42131 BF550
7111 5322 130 42755 BC847C
7180 4822 130 60373 BC856B
7181 5322 130 42755 BC847C
7182 5322 130 42755 BC847C
7183 5322 130 42755 BC847C
Note: Only these parts mentioned in the list are
normal service parts.
