12 - 6
ELECTRICAL PARTSLIST - CD BOARD
- MISCELLANEOUS - - CAPACITORS -
1800 4822 265 10925 SOCKET FFC 15P 2843 4822 122 31765 100pF 2% NP0 63V
1810 4822 242 73557 CST8,46MTW-TF01 2844 4822 126 13883 220pF 5% 50V
1823 4822 265 11207 SOCKET FFC 6P 2845 4822 126 13883 220pF 5% 50V
1824 4822 265 11207 SOCKET FFC 6P 2846 4822 124 40248 10µF 20% 63V
2848 4822 122 31765 100pF 2% NP0 63V
2849 4822 126 13883 220pF 5% 50V
2850 4822 126 13883 220pF 5% 50V
2851 4822 124 40248 10µF 20% 63V
2853 5322 126 11583 10nF 10% X7R 50V
- CAPACITORS - 2854 4822 124 11912 220µF 20% 6,3V
2801 4822 124 41751 47µF 20% 50V 2855 4822 124 11912 220µF 20% 6,3V
2802 4822 124 41751 47µF 20% 50V 2857 4822 124 12362 47µF 4V 20%
2803 4822 126 14226 82pF 5% NP0 50V 2860 5322 116 80853 560pF 5%NP0 63V
2804 4822 126 14226 82pF 5% NP0 50V 2861 4822 126 13344 1,5nF 5% 63V
2805 4822 126 14226 82pF 5% NP0 50V 2862 4822 126 14508 180pF 5% 50V NP0
2806 4822 126 13695 82pF 1% NP0 63V 2863 4822 126 14508 180pF 5% 50V NP0
2807 4822 126 11669 27pF 2864 4822 126 14508 180pF 5% 50V NP0
2808 5322 122 33538 150pF 2% NP0 63V 2865 4822 126 14508 180pF 5% 50V NP0
2809 4822 126 11669 27pF 2869 3198 024 44730 47nF Y5V 50V
2810 4822 126 13692 47pF 1% NP0 63V 2870 4822 126 13883 220pF 5% 50V
2811 4822 126 11671 33pF 2871 4822 126 13883 220pF 5% 50V
2812 4822 122 33741 10pF 10% NP0 50V 2872 4822 126 13883 220pF 5% 50V
2813 4822 126 14238 2,2nF X7R 50V 2873 4822 126 13883 220pF 5% 50V
2814 3198 024 44730 47nF Y5V 50V 2874 4822 126 13883 220pF 5% 50V
2815 4822 122 33777 47pF 5% NP0 63V 2875 4822 126 13883 220pF 5% 50V
2816 5322 122 32654 22nF 10% X7R 63V
2817 4822 124 40769 4,7µF 20% 100V
2818 3198 024 44730 47nF Y5V 50V
2821 4822 126 14305 100nF 10% X7R 16V
2822 4822 126 13344 1,5nF 5% 63V - RESISTORS -
2823 4822 124 42383 220µF 20% 4V 3728 4822 051 20479 47R 5% 0,1W
2824 4822 126 13751 47nF 10% X7R 63V 3745 4822 051 30338 3,3R 5% 0,062W
2825 4822 126 13344 1,5nF 5% 63V 3757 4822 051 20223 22K 5% 0,1W
2826 3198 024 44730 47nF Y5V 50V 3788 4822 051 20472 4,7K 5% 0,1W
2827 5322 126 11578 1nF 10% X7R 50V 3800 4822 117 13608 4,7R 5% 0,0016W
2828 4822 122 33777 47pF 5% NP0 63V 3801 4822 051 30154 150K 5% 0,062W
2829 3198 024 44730 47nF Y5V 50V 3802 4822 051 30102 1K 5% 0,062W
2830 3198 017 41050 1µF Y5V 10V 3803 4822 051 30273 27K 5% 0,062W
2831 4822 126 14043 1µF +80-20% Y5V 16V 3804 4822 051 30472 4,7K 5% 0,062W
2832 4822 122 33753 150pF 5% NP0 50V 3805 4822 051 30273 27K 5% 0,062W
2833 4822 126 13881 470pF 5% 50V 3806 4822 117 10361 680R 1% 0,1W
2834 4822 126 14506 270pF 5% 50V NP0 3807 4822 051 30152 1,5K 5% 0,062W
2835 4822 126 13881 470pF 5% 50V 3808 4822 051 30339 33R 5% 0,062W
2836 4822 124 41751 47µF 20% 50V 3809 4822 051 30339 33R 5% 0,062W
2837 3198 024 44730 47nF Y5V 50V 3810 4822 052 10478 4,7R 5% 0,33W
2838 3198 017 42230 22nF Y5V 50V 3811 4822 051 30102 1K 5% 0,062W
2839 4822 126 14305 100nF 10% X7R 16V 3812 4822 051 30474 470K 5% 0,062W
2840 4822 124 41751 47µF 20% 50V 3813 4822 051 30683 68K 5% 0,062W
2841 4822 126 13751 47nF 10% X7R 63V 3814 4822 051 30332 3,3K 5% 0,062W
2842 4822 124 21913 1µF 20% 63V 3815 4822 051 30472 4,7K 5% 0,062W
