Philips AZ1008 - Electrical Parts List; Front Board Electrical Parts; Main Board Electrical Parts; Miscellaneous Electrical Parts

11-1 11-1
PCS 107 182
ELECTRICAL PARTSLIST - FRONT BOARD
- RESISTORS -
3256 9965 000 07514 Rotary Volume.50KB X2
- COIL -
5401 9965 000 05604 Axial Inductor 100µH
- DIODE -
6261 9965 000 07515 LED Red
6402 9965 000 07516 Zener Diode
- TRANSISTORS -
7401 5322 130 42755 Trans BC847C
7402 5322 130 42755 Trans BC847C
- MISCELLANEOUS -
1250 9965 000 07513 Slide Switch
1400 4822 276 13797 Tact Switch
1401 4822 276 13797 Tact Switch
1402 4822 276 13797 Tact Switch
1403 4822 276 13797 Tact Switch
1404 4822 276 13797 Tact Switch
1405 4822 276 13797 Tact Switch
7403 9965 000 07517 LCD Display
Note: Only these parts mentioned in the list are
normal service parts.
ELECTRICAL PARTSLIST - CD VAM BOARD
- COIL & FILTER -
1810 4822 242 80997 Filter CST16,93MXW040-TF01
5802 9965 000 07238 Choke Coil 10mH
- IC & TRANSISTORS -
7801 9965 000 07519 IC TC9457F-014-907B-K1
7802 9965 000 07520 IC M63000SP
7803 9965 000 07521 IC TA2150FN
7804 5322 130 60123 Trans BC807-40
- MISCELLANEOUS -
1801A 9965 000 07518 FFC Cable 15P
Note: Only these parts mentioned in the list are
normal service parts.
ELECTRICAL PARTSLIST - MAIN BOARD
- COIL -
5200 4822 157 11012 Inductor 2.2µH
- DIODES -
6250 4822 130 83757 Diode BAS216
6251 4822 130 83757 Diode BAS216
6252 5322 130 30684 Diode 1N4002RL
6253 5322 130 30684 Diode 1N4002RL
6254 5322 130 30684 Diode 1N4002RL
6255 5322 130 30684 Diode 1N4002RL
6258 4822 130 83757 Diode BAS216
6259 4822 130 83757 Diode BAS216
6260 9965 000 07241 Zener 4.7V 0.5W
6261 5322 130 30684 Diode 1N4002RL
6262 4822 130 83757 Diode BAS216
6263 4822 130 83757 Diode BAS216
6265 4822 130 32778 Diode 1SS133
- IC & TRANSISTORS -
7250 4822 130 60511 Trans BC847B
7251 4822 209 31544 IC TA8227P
7253 4822 130 41327 Trans BC327-40
7254 4822 130 41327 Trans BC327-40
7255 4822 130 41327 Trans BC327-40
7256 4822 130 60511 Trans BC847B
7260 4822 130 41327 Trans BC327-40
Note: Only these parts mentioned in the list are
normal service parts.
ELECTRICAL PARTSLIST - MISCELLANEOUS
- CAPACITORS -
2001 5322 122 32654 22nF X10% 7R 63V
2002 5322 122 32654 22nF X10% 7R 63V
2003 4822 126 14043 1µF +80-20% Y5V 16V
- RESISTOR -
3002 4822 051 10008 0R 5% 0,25W
- MISCELLANEOUS -
1257 9965 000 07524 Slide Switch
1806 9965 000 07525 CD Door Switch
8102 9965 000 07526 FFC Cable 5P
8401 9965 000 07527 FFC Cable 12P
8501 9965 000 07528 FFC Cable 9P
8701 9965 000 07529 FFC Cable 6P
4822 265 10741 AC Socket (Not for -/17)
4822 265 20644 AC Socket (For -/17)
9965 000 07522 Speaker 8 Ohm 4' 3W
9965 000 07567
Transformer (For -/00/10/14)
9965 000 07585 Transformer (For -/01/05/11/16)
9965 000 07523 Transformer (For -/17)
4822 277 11887 Volt Selector (For -/01/11/16)
Note: Only these parts mentioned in the list are
normal service parts.
