Philips AZ1008 - Recorder Board Electrical Parts

11-3
PCS 107 184
ELECTRICAL PARTSLIST - RECORDER BOARD
- CAPACITORS - - RESISTORS -
2703 4822 124 81151 22µF 50V 3727 4822 116 52256 2K2 5% 0,5W
2704 4822 124 81151 22µF 50V 3730 4822 116 83868 150R 5% 0,5W
2706 4822 124 40433 47µF 20% 25V 3731 4822 116 52291 56K 5% 0,5W
2707 4822 124 40196 220µF 20% 16V 3732 4822 116 52182 15R 5% 0,5W
2708 4822 124 40433 47µF 20% 25V 3733 4822 111 30893 4M7 5% 0,2W
2709 4822 124 40433 47µF 20% 25V 3734 4822 050 21003 10K 1% 0,6W
2710 4822 124 41584 100µF 20% 10V 3743 4822 116 83883 470R 5% 0,5W
2711 4822 124 81151 22µF 50V 3744 4822 116 83883 470R 5% 0,5W
2712 4822 126 12878 1,5nF 10% 16V 3747 4822 116 83868 150R 5% 0,5W
2714 4822 126 12878 1,5nF 10% 16V 3748 4822 116 83883 470R 5% 0,5W
2715 4822 121 51387 10nF 20% 16V 3749 4822 116 83883 470R 5% 0,5W
2716 4822 126 12882 100nF +80-20% 50V 3761 4822 116 52289 5K6 5% 0,5W
2719 4822 126 13098 5,6nF 20% 16V 3762 4822 116 52289 5K6 5% 0,5W
2721 4822 126 12878 1,5nF 10% 16V
2722 4822 121 51387 10nF 20% 16V
- COIL -
2723 4822 126 12882 100nF +80-20% 50V 5701 4822 157 10371 Coil
2726 4822 126 13098 5,6nF 20% 16V
2727 4822 126 12878 1,5nF 10% 16V
- DIODE -
2728 4822 126 11714 4,7nF 20%
2729 4822 126 11714 4,7nF 20% 6704 4822 130 30621 Diode 1N4148
2730 2020 300 90561 1,2nF 10% 50V
- IC & TRANSISTOR -
2732 4822 122 10577 3,3nF 10% 16V
2733 4822 121 51387 10nF 20% 16V 7702 4822 130 40981 Trans BC337-25
2738 4822 121 51387 10nF 20% 16V 7705 4822 209 17498 IC AN7323
2739 4822 121 51387 10nF 20% 16V
- MISCELLANEOUS -
2750 4822 126 13098 5,6nF 20% 16V
2751 4822 126 13098 5,6nF 20% 16V 1707 4822 277 11504 Push Switch
1725 4822 265 11207 Connector Socket 6P
- RESISTORS -
3701 4822 116 52175 100R 5% 0,5W
3703 4822 116 83868 150R 5% 0,5W
3704 4822 116 83872 220R 5% 0,5W
3706 4822 116 52272 330K 5% 0,5W
3707 4822 116 52285 470K 5% 0,5W
3710 4822 116 52264 27K 5% 0,5W
3712 4822 116 52238 12K 5% 0,5W
3713 4822 116 83868 150R 5% 0,5W
3714 4822 116 83872 220R 5% 0,5W
3716 4822 116 52272 330K 5% 0,5W
3719 4822 116 52264 27K 5% 0,5W
3720 4822 116 52238 12K 5% 0,5W
3722 4822 116 52257 22K 5% 0,5W
3723 4822 116 52257 22K 5% 0,5W
Note: Only these parts mentioned in the list are
3726 4822 116 52256 2K2 5% 0,5W normal service parts.
