Supplied accessories
AC power cord
Top and front panels (See 1)
1
Source selector : CD/MP3,TUNER,
OFF
–
selects CD/MP3-CD or radio
–
switches off the set
2
VOLUME
–
adjusts volume level
3 LIFT TO OPEN
– lifts here to open the
disc door
4 9
–
stops disc playback;
–
erases a program;
5
PLAY/PAUSE 2; - starts or pauses disc
playback
6
Display
–
shows disc functions
7
ALBUM+ (up)
– For MP3-CD only: select albums
8 MODE – selects different play modes:
e.g. REPEAT or SHUFFLE (random order)
9 PROG – programs tracks and reviews the
program
0
SEARCH ∞§
– skips to the beginning of a current/
previous/ later track
– searches backwards and forwards within a
track
!
Frequency indicator
– shows the radio
frequency of your selected waveband
@
TUNING
– tunes to radio stations
#
BAND
–
selects wavebands, MW or FM
Back panel (See 1)
$ Telescopic antenna – improves FM
reception
% Battery door – open to insert 6 x 1.5V
R-14/ UM2/ C-cells
^ AC~ MAINS – inlet for power cord
CAUTION
Use of controls or adjustments or
performance of procedures other
than herein may result in hazardous
radiation exposure or other unsafe
operation.
This set complies with the radio
interference requirements of the
European Union.
Power Supply
Whenever convenient, use the power supply
cord if you want to conserve battery life.
Make sure you remove the plug from the set
and wall outlet before inserting batteries.
Batteries (not included)
1 Open the battery compartment door and
insert six batteries, type R-14, UM-2 or C-
cells, (preferably alkaline) with the correct
polarity as indicated by the "+" and "–" sym-
bols inside the compartment (See 1).
2 Replace the compartment door, making sure
the batteries are firmly and correctly in place.
The set is now ready to operate.
• Incorrect use of batteries can cause
electrolyte leakage and will corrode the
compartment or cause the batteries to burst:
• Do not mix battery types: e.g. alkaline with
carbon zinc. Only use batteries of the same
type for the set.
• When inser ting new batteries, do not try to
mix old batteries with the new ones.
• Remove the batteries if the set is not to be
used for a long time.
Batteries contain chemical substances, so they
should be disposed of properly.
Using AC power
1 Check if the power/mains voltage, as shown
on the type plate located on the
bottom of the set, corresponds to your
local power supply. If it does not, consult your
dealer or service center.
2 Connect the power cord to the
AC~ MAINS inlet and the wall socket. The
set is now ready for use.
3 To switch the set off completely, withdraw
the power cord from the wall socket.
4 Install the unit near the AC outlet and where
the AC power plug can be easily reached.
• Disconnect the power cord from the wall
socket to protect your set during heavy
thunderstorms.
The type plate is located on the bot-
tom of the set.
Helpful hints:
–To avoid unnecessary energy consumption,
always adjust the source selector to OFF
after using the set..
Basic functions
Switching on/off the set:
1 To switch on, adjust the source selector to
CD/MP3 or TUNER as desired.
2 To switch off, adjust the source selector to
OFF.
Adjusting volume
Adjust the volume with the VOLUME con-
trol.
Radio reception
1 Push the source selector to TUNER.
2 Adjust the
BAND
to MW or FM to select
your desired waveband.
3 Tu r n TUNING to tune in a radio station.
4 To switch off the radio, adjust the source
selector to OFF.
Helpful hints:
To improve reception
• For FM, extend, incline and turn the
telescopic antenna. Reduce its length if the
signal is too strong.
• For MW, uses a built-in antenna. Direct this
antenna by turning the whole set.
English Controls / Power Suppy
Power Supply Basic Function / Radio
