Mechanical and Dismantling Instructions
Dismantling Instruction
Step3: Dismantling Front Panel, disconnect the connectors (XP2, XP3,XP4)(Figure 6)
Figure 3
Step4: Dismantling Front Panel,
need release 2 snaps of Front Panel and 2 snaps of bottom cabinet , then gently pull the Panel
out from the set. (Figure 4 )
Figure 4
2-2
Detailed information please refer to the model set.
J4
XP5
XP3
XP2
CN7
J3
To Next Page
