BiPAP A40 user manual
8
Several accessories are available for use with the device. Contact your home care service provider to
purchase any accessories not included with your system. The following gure illustrates some of the
device connectors and features, described in the table that follows.
Air Outlet Port
AC Power Inlet
Filter Area
Accessory Slot (Cover Shown)
Side Cover
SD Card Slot
Nurse Call
Connector
DC Power Inlet
Connection
Feature Description
Air Outlet Port
Connect the exible tubing here.
Note: Heated Tubing should only be connected to the Air Outlet Port of the
compatible heated humidier and not to the Air Outlet Port of the therapy device.
SD Card Slot If applicable, insert the optional SD card here.
Accessory Slot
(with cover)
If applicable, an optional accessory such as the Broadband Oximetry modem can be
installed here. Refer to the instructions supplied with your accessory. When not using an
accessory, the cover must be in place on the device.
AC Power Inlet Connect the AC power adapter here.
DC Power Inlet Connect an external battery here using the Philips Respironics DC power cord.
Filter Area A reusable, gray foam lter must be placed in the lter area to screen out normal
household dust and pollen. A white ultra-ne lter can also be used for more complete
ltration of very ne particles.
Nurse Call
Connector
Connect a nurse call or remote alarm system to the device by connecting a nurse call or
remote alarm adapter cable to this connector.
Side Cover If using a humidier with the device, this side cover can be easily removed with the release
tab before attaching the humidier. Refer to the Humidier Manual for more information.
Detachable
Battery Module
Connection
If you are using the Philips Respironics Detachable Battery Module, attach the Battery
Module here and insert the battery into the module. See the instructions included with
the Detachable Battery Module for more information.
