CD713
CD Player
audio performance
• frequency range : 20Hz - 20kHz
• frequency response ripple : 0.9 |dB|p (20Hz - 20kHz)
• low level linearity : < 1 dB (1kHz, -90dB)
• signal-to-noise ratio : 98 dB (1kHz, A-weighted)
• dynamic range : 95 dB (1kHz)
• channel separation : 90 dB (1kHz)
• T.H.D. +N : 0.006%, -84dB (1kHz)
• wow and flutter : quartz precision
optical read-out system
• laser type : linear tracking, three spots
audio output
• output level : 2V RMS ±3dB
• minimum load : protected against short circuit
• impedance : 1k Ohm
digital output
• maximum output level : acc. IEC 958
• load impedance : 75 Ohm
power supply
• mains voltage : 230V (/00, +6% - 10%)
120V, 230V (/01, +6% - 10%)
• mains frequencies : 50-60Hz
• power consumption : < 15 W (in operation)
< 5 W (in standby)
• electrical requirements : IEC 65
set
• material / finish : metal, hot-stamp foil on polystyrene
• dimensions (incl. feet) : 435 x 86 x 265 mm (W x H x D)
• display : 2 colour starbust FTD
• weight : 2.9 Kg
package
• dimensions : 345mm x 515mm x169mm (D x W x H)
• weight (incl. set) : 3.6 Kg
accessories
• cinch cable
• instruction manual
• warrenty information
Printed in Singapore
Specifications subject to modification without notice.
700+ series CD player
standard product information
CD-Rewritable Playback
Philips has introduced CD recording as a
mainstream consumer audio application.
With the Philips CD-Recorders it is
possible to record CD-R discs (recordable,
write once) and CD-RW discs (rewritable,
erasable). CD-R discs are fully compatible
with the CD standard, and can therefore
be played back on any CD player. CD-RW
(rewritable) discs have a lower surface
reflectance than standard CD's and
therefore cannot be played by all today's
CD players. Our new range of CD
products offer CD Rewritable Playback.
These players are recognised by the "CD
Rewritable Playback Compatible" logo.
/00 /01 /14
Asia Pacific
Australia/NZ
Middle East/S Africa
Latam
Europe
•
E Europe
