8 - 3
MECHANICAL PARTSLIST (only for-X/78,-/55/51/56)
0001 996510027768 SERVO PCB-A(only for -X/78)
0002 996510027795 PANEL PCB-A(only for -X/78,-/55/56)
0003 996510029307 MAIN PCB-A(only for -X/78,-/55/56)
6501 996510027773 SHAFT-LOCK-RIGHT D=2.8
6502 996510027746 SHAFT-LOCK-Left
6503 996510027792 LCD COVER
6504 996510027727 BOTTOM_COVER
6505 996510027725 TOP_COVER
CD01 996510028981 Car CD Mechanism(only for -X/78)
FUSE1
!
996510029304 Fues 15A (only for -X/78)
PL02 996510027766 DECORAT DOWN
PL03 996510029306 DECORAT UP
PL05 996510027779 BUTTON OPEN
PL06 996510027708 BUTTON 1
PL07 996510027722 Slide-Right
PL09 996510027789 Panel Back
PL10 996510027737 Slide-Left
PL11 996510027767 BUTTON SOURCE
PL12 996510027729 RETURN BUTTON
PL13 996510027752 BUTTON EQ
PL14 996510027781 BUTTON SKIP
PL15 996510027714 LIGHTGUIDE
PL16 996510027747 BUTTON DIAL UP
PL17 996510027734 BUTTON DIAL DOWN
PL18 996510027745 BUTTON DBB
PL19 996510027788 RING
PL20 996510029305 LPL20 996510029305 Lens
PL21 996510027732 KNOB ENCODER
PL22 996510029308 USB COVER
PL23 996510027796 LCD Bracket
PL24 996510027769 LOCKER
PL25 996510027726 HANDSPIKE
PL26 996510027717 KNOB-EJECT W/Spray Shining
PL27 996510027731 Damper
PL28 996510027721 6M-GEAR
PL29 996510027778 LIGHT-GUIDE W/Silkscreen white
PL30 996510027787 CABINET
SOC1 996510029309 Socket Jensen 20P Housing
SPR1 996510027784 SPRING B
SPR2 996510027784 SPRING B
SPR3 996510027711 SPRING"E"
SPR3 996510027749 SPRING "D"
SPR4 996510027711 SPRING"E"
SPR4 996510028985 SPRING C WD=0.8mm
ACCESSORIES
TUN01 996510028975 Tuner Pack KST-C4011LVD-151M
ASS01 996510028991 Rubber End Rubber(Black)
ASS02 996510028973 Unit Key1mm EGIW/LOCKER
ASS03 996510028988 Machine Screw M5x8 Flat
RC01 996510027724 Remote Control (only for -X/78)
SC01 996510028983 Standard connector
Note: Only these parts mentioned in the list are
normal service parts.
0001 996510030544 SERVO PCB-A(only for -/55/51/56)
PL01 996510027735 Trim Plate
FUSE1
!
996510030485 Fues 15A (only for -/55/51)
PL04 996510027794 Panel Front
CD01 996510030494 Car CD Mechanism(only for -/55/51/56)
RC01 996510030543 Remote Control (only for -/55/51)
ACCESSORIES
0002 996510030551 PANEL PCB-A(only for -/51)
0003 996510030542 MAIN PCB-A(only for -/51)
M1
99651003551
3
METAL BELT
