ELECTRICAL PARTSLIST(only for -/98)
MAIN BOARD ASSEMBLY
ANT 996510027755 Antenna Socket
FFC2 996510027733 FFC 7 pin UL20624 P=1.0 L=35
FFC3 996510027739 FFC 24 pin UL20624 P=1.0 L=30
FU1
!
996510027762 W/15A Fuse
L1 996510027719 Ferrite Choke Transformer
S1 996510027777 Surface Mount Tact Sw H=5.2
S2 996510027744 Surface Mount Tact Switch 4Pin
S3 996510027758 Push Switch
TU1 996510027706 Tuner Pack KST-C4011LVD-151T
U10 996510027783 IC Supported USB/SD/MP3/WMA
U13 996510027763 IC L7809CV
U15 996510027776 IC L7805CV
U2 996510027763 IC L7809CV
U3 996510027707 IC TDA7388
U4 996510027736 IC LM2950L-50
U5 996510027771 IC LS4558F SOP-8 Op
U7 996510027782 IC PLL - DTS LP9257 SOP-20-300-
U8 996510027775 IC 7313
U9 996510027751 IC RDS Demodulator LP6579
XT2 996510027713 Crystal 4.332MHz
XT3 996510027748 Crystal 32.768 KHz
XT4 996510027774 Crystal 7.2MHz
SERVO BOARD ASSEMBLY
D703 996510027764 Infrared LED BIR-HM133A-TRB
D704 996510027764 Infrared LED BIR-HM133A-TRBD704 996510027764 Infrared LED BIR-HM133A-TRB
D705 996510027709 Rectifier SMD M7 1.0A/1000V
FFC1 996510027728 FFC 16 Pin UL2896 P=1.0 L=100
SW702 996510027718 Push Switch SW-111
U702 996510027753 IC IS42S16400F-7TL
U707 996510027754 IC S5L8030U
U708 996510027738 IC AP1117 3.3V SOT223-3L
U709 996510027715 IC AP1117-ADJ +/-2%1A
U710 996510027771 IC LS4558F SOP-8 Op
U711 996510027716 IC SA5888
U712 996510027786 IC S29AL004D70TF102
Y701 996510027765 Crystal SMD 16.9344MHz
9 - 1
