3
Check the car’s wiring carefully and connect
them to the supplied standard connector. E
1 Green/black strip Left speaker (Rear)
2 White/black strip Left speaker (Front)
3 Gray/black strip Right speaker (Front)
4 Purple/black strip Right speaker (Rear)
e RED Ignition key +12V DC when
ON/ACC
f BLUE Motor/electric antenna relay
control lead/Amplier relay
control lead
g BLACK Ground
h YELLOW To the +12V car battery which
is energized at all times
4
Connect the supplied standard connector to
the unit. F
Tip
The pin arrangement for the ISO connectors
•
depends on the type of vehicle you drive. Be
sure to make proper connections to prevent
damage to the unit.
Mount into the dashboard
1
If the car does not have an on-board drive or
navigation computer, disconnect the negative
terminal of the car battery.
If you disconnect the car battery in a car •
that has an on-board drive or navigation
computer, the computer may lose its
memory.
If the car battery is not disconnected, to •
avoid short-circuit, ensure that the bare
wires do not touch each other.
2
Ensure that car dashboard opening is within
these measurements: G
3
Remove the two screws on the top of the
unit. H
4
Remove the mounting sleeve with the
supplied disassembly tools. I
5
Install the sleeve into the dashboard and
bend the tabs outward to x the sleeve. J
Note
If the unit is not xed by sleeve but by the
•
supplied screws, skip this step.
6
Place the supplied rubber cushion over the
end of the mounting bolt. K
7
Slide the unit into the dashboard until you
hear a click sound. L
8
Reconnect the negative terminal of the car
battery.
Attach the front panel
1
Attach the trim plate. M
2
Insert the right side of the panel in the
chassis until it is correctly engaged.
3
Press the left side of the panel until the
mechanism locks it into place. N
