Philips CM12 - The Control Panels

Erwin Sabio Philips CM12 Alignment & Setup Manual Page 5
The Control Panels
Left Control Panel
Figure 2 The Control Panel located to the left of the microscope column.
Right Control Panel
Figure 3 The main control panel on the right hand side of the microscope.
9
Intensity Knob
16
Emission Meter
10
Fine Adjustment Knob
17
High Tension Button
11
Screen
18
Filament Control Knob
12
Screen Control Buttons
19
Ready Button
13
Power Switch
20
Focus/Focus Step Knob
14
Magnification Knob
21
Multifunction Control Knob
15
Beam Shift Knobs
9
10
11
12
16
17
4
18
15
19
20
21
13
14
