Philips DCM230 - Page 21

10 - 1
ELECTRICAL PARTSLIST - MAIN BOARD
- IC & TRANSISTORS -
Q19 994000004141 TRANSISTORS 2SD1936T-AC
Q20 994000004141 TRANSISTORS 2SD1936T-AC
Q501 994000004141 TRANSISTORS 2SD1936T-AC
Q502 994000004141 TRANSISTORS 2SD1936T-AC
Q8 996500039345 TRANSISTORS 2W 8050D
Q21 996500039345 TRANSISTORS 2W 8050D
Q22 996500039345 TRANSISTORS 2W 8050D
Q14 996500039345 TRANSISTORS 2W 8050D
Q6 996510000849 NPN TRANSISTORS 9014C
Q10 996510000849 NPN TRANSISTORS 9014C
Q15 996510000849 NPN TRANSISTORS 9014C
Q702 994000001193 TRANSISTORS KSB772YS
Q9 994000001193 TRANSISTORS KSB772YS
Q2 994000001193 TRANSISTORS KSB772YS
Q5 994000001193 TRANSISTORS KSB772YS
Q11 994000001194 TRANSISTORS KSD882Y
Q1 994000004338 SMD TRANSISTORS PMBT3904 SOT23
Q4 994000004338 SMD TRANSISTORS PMBT3904 SOT23
Q12 994000004338 SMD TRANSISTORS PMBT3904 SOT23
Q13 994000004338 SMD TRANSISTORS PMBT3904 SOT23
Q17 994000004338 SMD TRANSISTORS PMBT3906 SOT23
Q3 996510000992 TRANSISTORS SPD18P06P
D1 996500042437 CH-DIODE SS14 SMA/DO-214AC
IC6 996510002113 IC AP1501 (TO263-5L)
U8 996510002114 IC BR24C02F-WE2
IC201 994000002864 IC BU1924F
U3 996510002115 IC D2761 (SSOP10)
U1 996510002116 MCU GY383 (OTP)
IC3 994000004532 IC KA7808E (TO-220)
IC702 994000004622 IC LA6548NH HSOP28H
IC701 996500039807 IC LC78690NW-UPHI-E (SQFP80)
U2 994000002839 IC LM1117S-3.3 SOT-223
U9 994000002839 IC LM1117S-3.3 SOT-223
IC4 996500039808 IC SM LM324D (933984860668)
IC9 996510002117 IC OTI6889 (LQFP-80)
IC10 994000004607 IC PT2314
IC8 996510002118 IC SST39VF010-70-4C-WHE (1M)
IC104 996510002119 IC TA7291S
IC11 994000001203 IC TDA8947J/N3 (935274472112)
IC14 996500039809 IC YD4558 (SOP-8)
- MISCELLANEOUS -
D44 996510002112 RECTIFIER DIODE DL4001-T 1A 50V
D45 996510002112 RECTIFIER DIODE DL4001-T 1A 50V
D46 996510002112 RECTIFIER DIODE DL4001-T 1A 50V
D47 996510002112 RECTIFIER DIODE DL4001-T 1A 50V
D8 994000004363 SMD DIODE SOD80C PMLL4148L
D26 994000004363 SMD DIODE SOD80C PMLL4148L
D401 994000004363 SMD DIODE SOD80C PMLL4148L
D402 994000004363 SMD DIODE SOD80C PMLL4148L
D403 994000004363 SMD DIODE SOD80C PMLL4148L
D404 994000004363 SMD DIODE SOD80C PMLL4148L
