Philips DCM230 - Page 22

10 - 2
ELECTRICAL PARTSLIST - MAIN BOARD (CON'T)
- MISCELLANEOUS -
D405 994000004363 SMD DIODE SOD80C PMLL4148L
D407 994000004363 SMD DIODE SOD80C PMLL4148L
D9 994000004363 SMD DIODE SOD80C PMLL4148L
D17 994000004363 SMD DIODE SOD80C PMLL4148L
D23 994000004363 SMD DIODE SOD80C PMLL4148L
D24 994000004363 SMD DIODE SOD80C PMLL4148L
D6 994000004363 SMD DIODE SOD80C PMLL4148L
D27 994000004363 SMD DIODE SOD80C PMLL4148L
D4 994000004363 SMD DIODE SOD80C PMLL4148L
D2 994000004363 SMD DIODE SOD80C PMLL4148L
D7 994000004363 SMD DIODE SOD80C PMLL4148L
X1 996510000332 CRYSTAL 32.768KHZ (3x8mm)
XT201 994000004449 CRYSTAL 4.332MHZ HC-49/US
X4 994000004451 CRYSTAL 8.000MHZ HC-49/US
CF1 996510002120 CRYSTAL 12MHZ 20PF
X701 994000004551 CRYSTAL 16.9344MHZ HC-49/US
PH1 996510002121 PHONE JACK 3.6mm TC38-067-05-21
DC1 996510002122 DC JACK TC-18-013-03
F1
!
996510002426 CERAMIC FUSE 3.9x10.5mmW
Note: Only these parts mentioned in the list are
normal service parts.
