ELECTRICAL PARTSLIST - DISPLAY BOARD
- IC & TRANSISTORS -
Q19 996500039345 TRANSISTORS 2W 8050D
IC1 996510002124 IC (HOLTEK) HT1622
- COILS & FILTERS -
CN1-CON13 996510002126 9P FLAT CABLE L=255mm (LCD-MAIN)
- MISCELLANEOUS -
D7 994000004363 SMD DIODE SOD80C PMLL4148L
D11 994000004363 SMD DIODE SOD80C PMLL4148L
REM2 996510002125 OPTIC SENSER RPM7138-V4
9 996510002127 LCD BRACKET
19 996510002128 BACKNNIGHT LENS
D19 996500042438 LED LAMP 2x5x7mm (WHITE)
D20 996500042438 LED LAMP 2x5x7mm (WHITE)
D21 996500042438 LED LAMP 2x5x7mm (WHITE)
D22 996500042438 LED LAMP 2x5x7mm (WHITE)
LCD1 996510002123 LCD DISPLAY SDH-DA1480-TP-1
Note: Only these parts mentioned in the list are
normal service parts.
10 - 3
