Technical Specification and Connection Facilities
1-5
3. Technical Specifications
Power Supply
3.1.1 Type and versions
3.1.1.1 SMPS for main unit
Build-inSMPS will be used for all models and stroke versions.
All using figure '8' socket, will cater for all versions:
Versions Region/Country SMPS Detachable mains cords
nip-3 )50/( KU & nip-2 dnuor )21/( UE KU / EPORUE 50 / 21
37 NAFTA
UL flat pin (non-polarized)
nip-2 dnuor deifitrec ORTEMNI MATAL 55
98 APAC
1) 100 ~240Vac nom. (wide
range from 90V~264Vac limit)
used in all versions except
India.
Frequency: 47~63Hz.
EU round 2-pin
94 India
2) 100 ~310Vac limit (India
compatible with up cost) used
only for India.
Frequency: 47~63Hz.
EU (/12) round 2-pin
All requirements per defined for each country should be met with sufficient testing.
3.1.1.2 Adaptor for Docking
AC/DC adaptor 5V/ 2.1A for docking, wide range input voltage.
3.1.2 Surge Immunity (Lightning Test)
The product shall withstand mains interference’s of:
Differential mode:
• 2kV/2 ohm criteria C for Europe.
• 6kV/12 ohm criteria C for NAFTA.
Parameters:
• Bi-wave
• Open circuit voltage: 2/50us
• Short circuit current: 8/20us
• From +/1kV to +/-2kV (for Europe) or +/-6kV (for Nafta) in steps of 1kV.
• 10 shots per combination.
• One shot per minute.
• Serial impedance: 2 Ohm for Europe, 12Ohm for Nafta.
• Polarity and phase: Positive (phase 90º) & Negative (phase 270º)
