Philips DVD740VR/051 User Manual

1-12-1 H9330WFP
WF1
V-OUT E-E
10usec 50mV x 10
WAVEFORMS
(TP751 of Main CBA)
WF1
UPPER
WF2
LOWER
V-OUT 0.1V x 10
RF-SW 0.5V x 10
50usec
(TP751 of Main CBA)
(TP302 of Main CBA)
WF5
C-PB 10mV x 10
RF-SW 0.5V x 10
5msec
UPPER
LOWER
WF2
(TP302 of Main CBA)
(TP301 of Main CBA)
1-12-2 H9330DWFP
WAVEFORMS
NOTE:
Input
CD: 1kHz PLAY
(WF4~WF6)
DVD: POWER ON (STOP) MODE
(WF1~WF3)
WF6
SPDIF
Pin 18 of CN1601
1V 0.2usec
WF1
Pin 5 of CN1601
WF3
Pin 9 of CN1601
WF4
AUDIO-L
Pin 13 of CN1601
1V 0.5msec
WF5
AUDIO-R
Pin 15 of CN1601
1V 0.5msec
WF2
Pin 7 of CN1601
VIDEO-Y
0.2V 20usec
VIDEO-CVBS
0.5V 20usec
VIDEO-C
0.2V 20usec

Philips DVD740VR/051 Specifications

General

Video Format	MPEG-2
Progressive Scan	Yes
Weight	2.5 kg
Playback Formats	DVD, DVD+R, DVD+RW, DVD-R, DVD-RW, CD, CD-R, CD-RW
Recording Format	DVD+R, DVD+RW, DVD-R, DVD-RW
Audio Output	Dolby Digital
Connectors	Composite, S-Video, Component, HDMI
Output Resolution	720p, 1080i
