M echanical and Dism antling Instru c tions
Dism antling Instru c tion
The follow ing guidelines show how to dism antle the player.
Step1: Rem ove 5 screw s around the Top Cover. A nd rem ove
it (Figure 1)
Step2: If it is necessary to dism antle Loader or Front Panel,
It should be rem ove the front door assem bly first. (Figure 2)
If the trace can’t open in normal way, you can m ake it by
pushing the guider m anually using the slot below the bottom
chassis with a tool. (Figure 3)
Note: Make sure to operate gently otherwise the guider would
be dam aged.
2-1
Figure 2
Figure 1
Figure 3
Push the guider until the
trace out. M ake sure to
operate gently to avoid
dam a
eha
enin
.
