14
2. Setting up the monitor
322E1C/325E1C/328E1C
1. Place the display face down on a
smooth surface. Pay attention not to
scratch or damage the screen.
2. Use screwdriver to loosen the
screw located at the bottom of the
base,and remove the base from the
stand.
1
2
3. Remove the hinge cover from
monitor body by using your fingers.
4. Use a screwdriver to remove the
screws on the arm,and then detach
the arm/stand from the monitor.
Note
This monitor accepts a 100mm x 100mm
VESA-Compliant mounting interface.
VESA Mounting Screw M4. Always
contact manufacturer for wall-mount
installation.
100mm
100mm
Warning:
This product is curve design, when
attach / detach the base, place the
protective material under the monitor
and do not press down the monitor to
avoid the damage.
Note
Please purchase the appropriate wall
mount; otherwise the distance between
the back-plug-in signal cable and the
wall would be too short.
To Next Page
