Philips EP5310/10 - Test Mode PHI 5000

PHI 5000 04 DIAGNOSTIC MODE
1/8
4.1. Test Mode PHI 5000
The Test Mode is organized into 6 dierent pages, each level the coee machine can execute
dierent commands:
Page 0: The display shows:
a) Firmware version.
b) Version of machine
c) Voltage of PCB.
d) Main supply frequency (50 or 60 Hz).
Page 1: Keyboard and display’s colour test:
a) Z1 button
b) Z2 button
c) Z3 button
d) Z4 button
e) Z5 button
f) Z6 button
g) Z7 button
h) Backlight colors
Page 2: Input signals test:
a) Water level sensor
b) Micro-switch door closed/opened
c) Microswitch presence of the Brew Unit
Page 3: Low voltage loads test:
a) Brew Unit movement upward and downward (24V DC)
Page 4: High/Low voltage loads test (Pump, E.Valve ) :
a) Pump (230V AC and 120V AC)
b) DC Solenoid valve (24V) ( The door must be closed !!)
c) Flow-meter
Introduction
This document describes the Test Mode of the PHI 5000 Coee Machine. This application is used
in order to test the machine in its mechanics and electronic components.
To enter Test Mode
The machine enters in Test mode by holding pressed together Z1 and Z6 buttons while switching
on the machine by the main switch on the backside of the CA.
Once entered in Test Mode, the display shows the rmware version (Level 0).
Z1
Z2
Z3
Z6
Z7
Z5
Z4
