EPIQ 5 & 7 Training Manual
© 2016 Conquest Imaging
25
Voltages
Essential?
Function
+3.3 VDC
Yes
Provides logic power to the digital
circuitry (CPUs and ICs) throughout the
system.
5V_STBY
Yes
This power is on even when the
system is off, to control the power-on
signal from the motherboard.
V_ACC
Yes
Powers the solenoids that control the
control panel articulation capabilities.
Enabled/Disabled via the button on
the system handle.
+24VDC
No
This voltage is from the +24 Vdc
converter and is used to generate
V_ACC and VDC_SYS.
Battery
Charging
Voltages
No
The VPPM monitors the system
battery voltages to regulate and
coordinate the charge on the batteries.
120 VAC
Inverter
Voltages
No
Produces isolated AC power for the
peripherals. Connections are on the
side of the VPPM which is accessible
from the rear of the system.
Optional Battery Operation
The ultrasound system operates using the AC input power. The
batteries are not intended for imaging or sustained system operation.
The main benefits of the batteries are not having to shut down for
transport and having time for normal shutdown in the event of
unexpected power failures.
The functions provided by the optional batteries are:
 Ensure proper system shutdown in the event of an unexpected
AC power loss.
 Provides 20 minutes of 24VDC power for quick system startup
and system transport. After 20 minutes the system will undergo
normal OS shutdown.
