EPIQ 5 & 7 Training Manual
© 2016 Conquest Imaging
decreases to the original size.
5. Turn Depth. Verify the changes in depth.
6. Press Zoom to display the High Definition (HD) Zoom box.
7. Use the trackball and its buttons to move and resize the HD
Zoom box.
8. Press Zoom to enlarge the ROI.
9. Press Zoom to return to 2D imaging.
10. Adjust Res/Spd. Verify that the icon updates on the touch
screen.
11. If a curved array or sector transducer is connected, adjust
Sector Width to reduce the field of view, and restore it to the
default size.
12. Turn 2D Opt and verify the setting changes on the touch
screen. Verify that the MI and TI values change on the imaging
display.
13. Turn Loop Length. Verify that the setting changes on the touch
screen.
14. Press iSCAN. Verify that the iSCAN icon changes to an amber
color for about 3 seconds.
15. Press Freeze. Verify that the image is frozen and that the
cineloop cursors and frame number are displayed below the
image.
16. Use the Aquire1 or Aquire2 to print the image (usually Acquire
2).
Testing Color and CPA Imaging
Successful execution of this test verifies operation of the Color and
CPA controls and the other touch screen knobs (soft keys) not used in
2D imaging.
