EPIQ 5 & 7 Training Manual
© 2016 Conquest Imaging
LED Indicators
Many of the circuit board and modules have LEDs that indicate
current power status which are useful for troubleshooting.
Power Supply LED Indicators
The LEDs visible on the back of the VPPM indicate:
Battery status (see table)
ATX and PC voltages are ready
Rear Panel of VPPM
Channel Board LED Indicators
The Channel Board LED Indicators can indicate proper operation. They
cannot be accessed for a single photo. See the instructor power point
presentation associated with this manual for a video showing normal
operation.
