Philips FC7070 - Parts List

FC7070/01 /11 /61 /81
5-9
PARTS LIST
Pos Service code Description
1
2
3
4
5
4322 005 32941
4322 005 31191
4322 009 00611
4322 005 26841
4322 005 30281
Dirty water tank lid assy
Dirty water tank (excl. lid)
Cap
Clean water tank assy (excl. cap)
Upper stick cover
6
7
8
9
10
4322 005 30121
4322 006 24402
4322 003 39361
4322 003 39381
4322 003 39421
Microswitch with cables & conn.
Main PCBA
Handle backpart
Grip rear
Cord hook
11
12
13
14
4322 005 31291
4322 005 31831
4322 005 26861
4322 005 30271
4322 001 74571
Sensor interface PCBA
Motor assy 220V
Motor assy 230V
Lower stick cover
Clean water tube
15
16
17
18
19
4322 003 39141
4322 003 39151
4322 003 39131
4322 003 39121
4322 003 39671
Handle clean water tank
Clean water tank interface
Hinge right
Hinge link
Hinge left
20
21
22
23
24
4322 003 39111
4322 005 32851
4322 003 42281
4322 003 38851
4322 003 38721
Handle dirty water tank
Joint housing
Hood side panel left
Tilt mechanism pedal
Nozzle side panel left
25
26
27
28
4322 005 26761
4322 005 32101
4322 006 24601
4322 005 32401
4322 001 74971
Hood assy (excl. side panels)
Hood assy (excl. side panels) CN
Nozzle PCBA
Microswitch assy
Pump cover
Pos Service code Description
29
30
31
32
33
4322 006 96191
4322 003 38931
4322 003 44371
4322 005 26781
4322 005 30321
Clean water pump
Brush cover
Safety bar holder
Brush assy
Mid bar assy
34
35
36
37
38
4322 005 32931
4322 003 38701
4322 003 38691
4322 003 38911
4322 003 40351
Brush coupling assy
Spoiler clamp back
Spoiler clamp front
Collar
Tilt mechanism curtain
39
40
41
42
4322 003 38951
4322 003 38711
4322 003 40341
4322 005 31851
4322 005 26721
Hood side panel right
Nozzle side panel right
Joint clamp
Drive train assy 220V
Drive train assy 230V
43
44
45
46
47
4322 001 74621
4322 005 26741
4322 005 26731
4322 003 38651
4322 001 74641
Brush cover seal
Rear wheel assy
Front wheel assy
Driptray
Rubber spoiler
48
49
50
51
52
4322 005 31571
4322 005 31262
4322 005 32022
4322 003 39372
4322 005 33241
Dirty water tank full sensor
Power cord EU
Power cord Swiss
Grip front
Power cord HK
53
54
4322 005 31942
4322 005 26851
4322 005 32031
4322 005 33221
4322 005 31951
Power cord CN
Upper stick assy EU
Upper stick assy Swiss
Upper stick assy HK
Upper stick assy CN
