Philips FC8734/01 - Telescopic Tube; Accessory Holder (Specific Types Only)

Telescopic tube
1 Positionthenozzleontheoorandholdthetubeatanangleof45°
totheoor.
2 Move the tube lock up or down until the handgrip is at hip level.
3 To connect the tube to a nozzle, press the spring-loaded lock button
on the tube and insert the tube into the nozzle. Fit the spring-loaded
lock button into the opening in the nozzle (‘click’).
- To disconnect the tube from the handgrip, press the spring-loaded lock
button and pull the handgrip out of the tube.

1 Slide the accessory holder with accessories onto the handgrip
(‘click’).
2 To detach the accessory holder, squeeze the release levers
together (1) and slide the accessory holder off the handgrip (2).
ENGLISH10
