3 Basic Operation
32
with Battery
Option
Left Side
Each of the fetal sensor sockets accepts any fetal transducer, one Avalon CL or one Avalon CTS
Cableless Fetal Transducer System base station, or an event marker.
Bottom
There are five optional interfaces available for the Avalon FM20/30 monitor:
• LAN/RS232 system interface
• Dual PS/2 interface
• Dual MIB/RS232 interface
• Flexible Nurse Call interface
• USB ports interface
1 On/Standby button with power LED
2 MSL connector for external power
supply
1 SpO
2
socket (optional)
2 Noninvasive Blood Pressure
socket (optional)
3 Fetal sensor sockets
