Why is there light or no trace on my Philips Avalon FM20?
The issue of light or no trace on your Philips Monitor could stem from a few reasons. It might be due to using the wrong type of paper. It could also be caused by a dirty printhead. In the case of FM20/30 models only, the paper might be misaligned because the drawer isn't fully closed.
What to do if my Philips Monitor displays 'End of paper noted' prematurely?
If your Philips Monitor indicates 'End of paper noted' before the paper pack is actually finished, it may be due to a bad paper feed or using the wrong type of paper. Check the paper feed and ensure you are using the recommended paper.
General| Dimensions | 345 mm x 340 mm x 145 mm (13.6 in x 13.4 in x 5.7 in) |
|---|---|
| Weight | Approx. 6.7 kg (14.8 lbs) without options; Approx. 7.2 kg (15.9 lbs) with options |
| Resolution | 800 x 600 pixels |
| Display Size | 12.1 inches |
| Parameters Monitored | Fetal Heart Rate (FHR), Uterine Activity (TOCO) |
| Connectivity | USB |
| Power Supply | AC 100-240V, 50/60Hz |
| FHR Range | 50 – 210 bpm |
| TOCO Range | 0 – 100 relative units |
| Battery Type | Lithium Ion |
| Battery Life | Up to 4 hours |
| Paper Speed | 1 cm/min, 2 cm/min, 3 cm/min |
| Recorder Type | Thermal array |
| Screen Size | 12.1 inches |
Details warnings and cautions for safe operation.
Highlights electrical safety precautions and warnings.
Covers installation procedures and responsibilities.
Outlines procedures for maintenance, repair, and care.
Details ambient operating and storage conditions for the monitor and transducers.
Defines essential performance criteria for fetal monitors.
Provides a checklist to document monitor installation steps.
Details how to assemble and install mounting hardware for the monitor.
Covers pre-use checks and configuration settings for the monitor.
Provides a block diagram of the monitor's main assemblies and components.
Describes the Main CPU Board's control of the human interface and data processing.
Provides a block diagram of transducer hardware components.
Describes the LAN and RS232 ports for system connectivity and data export.
Explains supported USB devices and connection limitations.
Outlines general requirements for connecting the monitor to a network.
Highlights customer responsibility for data privacy and network security.
Suggests a timetable for performing various tests and maintenance.
Lists safety tests performed on the monitoring system.
Details NBP test procedures, including accuracy, leakage, linearity, and valve tests.
Tests the performance of the SpO2 measurement.
Covers proper handling, maintenance, and disposal of the battery.
Identifies qualified personnel for performing repairs.
Guides users through troubleshooting categories and recommended actions.
Lists common parameter INOPs and troubleshooting steps.
Details symptoms, causes, and remedies for boot phase failures.
Troubleshoots issues related to transducer detection and function.
Lists part numbers and descriptions for monitor components.
Lists part numbers and descriptions for various transducers.
Lists part numbers and descriptions for patient modules.
Details procedures for disassembling and reassembling the top cover.
Instructions for removing the display assembly.
Step-by-step guide for replacing the display assembly.
Details the disassembly of the recorder unit.
Instructions for replacing the stepper motor.
Instructions for removing the NBP assembly.
Details how to remove the SpO2 assembly.
Details the procedure for removing the main CPU board.
Instructions for removing the front end assembly.
Instructions for exchanging the transducer cable.
Lists available upgrade options for FM20/FM30 monitors.
Covers how to install various upgrade options.
Lists temperature, humidity, and altitude ranges for monitor and transducers.
Details physical attributes of the fetal monitor, including dimensions and weight.
Details fetal monitor performance specifications for alarms and real-time clock.
Lists performance specifications for NBP, including measurement ranges and accuracy.
Details SpO2 accuracy and performance with various sensors.
Lists specifications for the built-in thermal array fetal trace recorder.
Lists regulatory compliance and CE marking information.
Lists compliance with major international safety and performance standards.
