2 Site Preparation
17
WARNING
NEVER run power cables through the same conduit or trunking used for system cables.
• Installing wall boxes
It is the customer's responsibility to provide and install wall boxes to house face plates. The customer
must notify the Philips installation coordinator of which size is to be used.
Procedures for Philips Personnel
Before you begin the procedures in the installation sections, ensure that the customer has completed
all necessary preparations outlined in the previous section .
Site Requirements
The site requirements are listed in this section.
Space Requirements
The situating of the monitor should be planned such that the nursing staff are able to monitor the
patient with relative ease, with all patient connectors and controls readily available, and the displays
clearly visible. The location should also allow access to service personnel without excessive disruption,
and should have sufficient clearance all round to allow air circulation.
Dimensions and weight:
Monitor:
Size (W x H x D): 335 x 286 x 133 mm (13.2 x 11.3 x 5.2 in.)
Weight; 5.1 kg (11.2 lb.) with battery option #25 5.3 kg (11.7 lb.)
Transducer:
Size (diameter): 83 mm (3.27 in)
Weight (without cable): 190 g (6.7 oz)
