3 Installation Instructions
26
Unpacking and Checking the Shipment Fetal
Monitors
Inspect the delivery on arrival. The monitor and any supporting options ordered are packed in
protective shipping cartons.
Initial Inspection
Open the shipping container(s) and examine each part of the instrument for visible damage, such as
broken connectors or controls, or scratches on the equipment surfaces. If the shipping carton/
container is undamaged, check the cushioning material and note any signs of severe stress as an
indication of rough handling in transit. This may be necessary to support claims for hidden damage
that may only become apparent during subsequent testing.
1
For assessment of maternal heart rate only.
2
Ships with Patient Module (K03).
7 Check/set paper speed (see “Checking/Setting Recorder Speed” on
page 36 )
8 Perform system test as necessary (see “Performance Assurance Tests”
on page 83)
9 For monitors with the battery option (#E25) confirm that the battery
can be charged, and that the monitor can be powered by the battery
10 Test transducers (see “Transducers and Patient Modules; Functional
Tests” on page 91)
Step Task Check when
done
System Components, Accessories and Supplies FM20 FM30
Toco
+
Transducer (with belt clip) - optional
Toco MP Transducer (with belt clip)
1
11
US Transducer (with belt clip) 1 1
Patient Module for DECG/MECG/IUP optional
1
optional
DECG Reusable Leg plate Adapter Cable - 1
MECG Adapter Cable - 1
IUP Adapter Cable
2
- optional
External Power Supply and MSL Cable optional optional
Event Marker optional optional
Fetal Paper Pack (country-specific, installed) 1 1
Power Cord 1 1
Printed Instructions for Use 1 1
Documentation DVD: includes FM20/30 Service
Guide, FM40/50 Service Guide, Instructions for Use
(including localized versions), and Training Guide
11
