8 Troubleshooting
115
Alarm Tones
Alarm Behavior
If your monitor did not alarm in the way in which the end user expected it to, please consult the
Instructions for Use for possible setup issues, or configuration settings which could affect alarm
behavior.
Fetal Recorder
LAN cable connected, IP address assigned, monitor connected to OB TraceVue/
IntelliSpace Perinatal.
OB TraceVue/IntelliSpace Perinatal may send a prompt message, indicating a possible
problem.
Icon Explanation
Symptoms Possible Causes of Failure Failure Isolation and Remedy
INOP Message Speaker
Malfunct
is displayed
Speaker cable disconnected
Reconnect the speaker cable.
Speaker defective
Replace the speaker.
Sound amplifier on the Main CPU Board
defective
Replace the Main CPU Board.
An alarm occurs, but no
alarm sound is issued.
Volume is set to 0 Increase the volume.
Speaker defective
Replace the speaker.
Sound amplifier on the Main CPU Board
defective
Replace the Main CPU Board.
Symptom Possible Cause Corrective Action
A Paper empty warning is
issued in the status line at
the bottom of the screen,
but paper is not out.
The drawer is open. Close the drawer.
A paper jam occurred.
Open the drawer, remove paper, tear off the
crumpled paper and re-load, or load a new
pack of paper. Close the drawer.
The paper sensor is dirty.
Clean the paper sensor.
The paper sensor is defective.
Exchange the paper sensor -- see “Repair
and Disassembly” on page 139 and “Parts”
on page 125.
