ROW
FR760
A/V Surround Receiver
Technical Specifications
Connections
• Audio inputs/outputs : 6 input sources, 2 output connections
- CD : in
- CDR/Tape : in/out
- TV : in
- VCR : in/out
- 6CH/DVD : 6 analogue inputs (L, R, C, R
L, RR, Sw)
- Front AV/Game : in
- Headphone : 6.3 mm
• Video inputs/outputs : 4 input sources, 2 output connections
- DVD : in
- TV : in
- VCR : in/out
- Monitor : out
- Front AV/Game : in
• Speaker connections suitable for speakers ≥ 6 Ohm
- left, right, center : click-fit connection
- rear left, right : click-fit connection
• Miscellaneous connections
- Cinema Link system control bus : 2
- subwoofer pre-out : 1
- center pre-out : 2
- mains outlet : 1 (maximum 100W)
- AM antenna : loop type
- FM antenna : coaxial 75 Ohm
Amplifier
• Power output stereo mode 6 Ohms, 1kHz, 0.7% THD, DIN
- left, right : 2 x 100 W
• Power output surround mode 6 Ohms, 1 KHz, 0.7% THD
- left, right : 2 x 100 W
- center : 100 W
- rear left, right : 2 x 100 W
• Amplifier characteristics
- total harmonic distortion : 0.05 % (1 kHz, 5W output)
- power bandwidth (D<0.7%) : 20 Hz – 20 kHz
- frequency response (linear) : 10 Hz – 30 kHz, ± 1 dB
- signal-to-noise ratio (weighted) : > 85 dBA, (acc. IHF, 1KOhm)
- channel separation (crosstalk) : ≥ 55 dB, 1 kHz
• Controls
- bass : 100 Hz, (-9dB … +9dB)
- treble : 10 kHz, (-9dB … +9dB)
- loudness : +6 dB (100Hz,-30dB), +3 dB (10kHz,-30dB)
• Surround
- modes : ProLogic, Center Phantom, 3-Stereo, Hall
- delay : 15 to 30ms (steps of 5ms)
• Audio input sensitivity
- CD : 250 mV / 47 kOhms
- CDR/Tape : 250 mV / 47 kOhms
- TV : 250 mV / 47 kOhms
- VCR : 250 mV / 47 kOhms
- 6CH/DVD : 250 mV / 47 kOhms
- Front AV/Game : 250 mV / 22 kOhms
• Audio output sensitivity
- CDR/Tape : 250 mV / 1 kOhm
- VCR : 250 mV / 1 kOhm
- subwoofer pre-out : 0.8 V / 1 kOhm
- center pre-out : 0.8 V/ 1 kOhm
- headphone : 3 V / 60 Ohm
Tuner (typical values)
• FM section
- wave range : see table on back side
Sensitivity at 75 Ohm
- Mono 26 dB S/N : 17 dBf (/01)
15 dBf (/00)
- Stereo 46 dB S/N : 41 dBf
- Selectivity : 55 dB at 300 kHz
- Distortion mono/stereo : 0.9%, 0.8% (/01)
0.85%,0.3% (/00)
- Frequency response : 63Hz-12.5KHz, ±1dB
- S/N ratio mono/stereo : 65 / 55 dB
- Stereo separation (1KHz) : 27 dB (/01)
35 dB (/00)
- Image rejection : 48 dB (/01)
100 dB (/00)
- IF suppression : 85 dB (/01)
100 dB (/00)
Sub carrier suppression
- for 19 KHz : 30 dB
- for 38 KHz : 50 dB (/01)
37 dB (/00)
• AM section
- Wave ranges : see table on back side
- Sensitivity (MW) : 1.5 mV/m
- Selectivity : 30 dB
- IF rejection : 64 dB (/01)
50dB (/00)
- S/N ratio : 48 dB (/01)
50dB (/00)
General
• Power supply
- mains voltage : see table on backside
- power consumption : < 2W (in standby)
: ≈ 255W (in 5 channel operation)
- electrical requirements : IEC65
• Remote control
- keys : 42-keys
- codes : RC5, RC6
- type : Philips Audio & Video products
• Set
- material / finish : metal, hot-stamp foil on ABS
- dimensions (incl. feet) : 435mm x 135mm x 350mm ( W x H x D )
- display : 2 color starburst FTD
- weight : 9.4 Kg
• Package
- dimensions : 519mm x 216mm x 488mm ( W x H x D )
- weight (incl. set) : 10.8 kg
• Accessories
- remote control
- 2 AA carbon/zinc batteries
- instruction manual
- warrantee information
- AM loop + FM wire antenna
- scart audio adaptor (/00)
