SERVICE TOOL
Audio Signals Test Disc 1.00.0... icceeeeeeeeseeeeee 4822 397 30184
MEASUREMENT SETUP
Tuner FM
Bandpass
DUT 250Hz-15kHz LF Voltmeter
e.g. 7122 707 48001 e.g. PM2534
RF Generator
e.g. PMS5326
50Q
hh
Ri=
$/N and distortion meter
eg. Sound Technology ST1700B
/
1e) ie)
Use a bandpass filter to eliminate hum (50Hz, 100Hz) and disturbance from the pilottone (19kHz, 38kHz).
Tuner AM (MW,LW)
Bandpass
250Hz-15kHz LF Voltmeter
e.g. 7122 707 48001 e.g. PM2534
RF Generator
e.g. PM5326 g : .
prrooon
1
3/N
and
distortion
meter
i
a
{fo
os
eg.
Sound
Technology
ST1700B8
i rd \ if
|B) | | Frame aerial Cry)
ed | @g. 7122 707 89001
(£ ! le) fe)
: \
t |
i |
pete en Berea |
a
——
To avoid atmospheric interference all AM-measurements have to be carried out in a Faraday’s cage.
Use a bandpass filter (or at least a high pass filter with 250Hz) to eliminate hum (50Hz, 100Hz).
