8. GENERAL INFORMATION
CD MAIMTEMAMCE _
• Never write on the printed side of a CD.
• Do not attach any stickers to the CD.
• Keep the shiny surface of the disc clean. Use a soft lint-free
cloth and always wipe the disc in a straight line from centre
to edge.
• Never use cleaning agents for conventional records.
• Detergents or abrasive cleaning agents should not be used
either.
SYSTEM MAINTENANCE _
• A chamois leather slightly moistened with water is sufficient
for cleaning the system.
• Do not use cleaning agents containing alcohol, spirits,
ammonia or abrasives.
• Do not leave the system for any length of time in direct sun¬
light or other places where high temperatures can occur,
such as in the vicinity of heating apparatus.
• Do not expose the system to humidity or rain.
FAULTS AND THEIR LIKELY CAUSES _
If a fault occurs, run through the points listed below before tak¬
ing your set to service for repair.
CD player
- The lens may steam up when the set is taken from a cold
into a warm environment. Playing a CD is then not possible.
Let the set acclimatize for a while.
- Check that there is a CD in the compartment and that the
CD has been inserted correctly with the printed side up;
- Check whether the CD is dirty, badly scratched or warped;
Cassette deck
- Dust and dirt on the heads can influence the sound repro¬
duction and the quality of the recording. Clean the heads
{see Cassette deck maintenance).
Tradeshow mode
The system has a tradeshow that describes various features
available in the system. The system is in the tradeshow mode
if the display of the amplifier shows the message PHILIPS
MINI FW80 after switching on the power, followed by a series
of other messages.
• To leave the tradeshow mode and enter the normal standby
mode: switch off the power and keep the buttons
PHONO/AUX 9 and DCC 10 (on the amplifier) pressed while
switching on the power again with SYSTEM POWER
OFF/STANDBY 1 (on the amplifier).
• To enter the tradeshow mode: keep the buttons
PHONO/AUX 9 and DCC 10 (on the amplifier) pressed while
switching on the power with SYSTEM POWER OFF/STAND¬
BY 1.
Problems with the whole system
Electrostatic charge may cause unexpected symptoms, e.g. a
unit fails to react to any key pressed. The best thing to do is to
reset the unit by switching off the power.
• Press the SYSTEM POWER OFF/STANDBY on the front of
the amplifier to switch off the power for the whole system.
• After a few seconds switch on the power again by pressing
SYSTEM POWER OFF/STANDBY again. The system now
enters the standby mode.
TECHNICAL DATA _
(subject to modification)
Amplifier _
• Output power: 2 x 60 W RMS / 6 Q / THD 10% (EQUALIZER
setting at 0 dB)
• Power bandwidth: 20 - 40 000 Hz
• Frequency response: 40 - 20 000 Hz
• Signal-to-noise ratio: > 75 dBA (1EC)
• Stereo separation: > 50 dB (IHF)
• Input sensitivity
Tuner: 200 mV
Phono MD: 2,5 mV
CD: 350 mV
Tape: 350 mV
DCC: 250 mV
Aux: 250 mV
• Outputs
Tape out: 250 mV
DCC out: 250 mV
Loudspeakers: >60
Headphones: 80-1000 C l (5 Vemk-120 Q)
Tuner
• FM Wave range: 87,5 -108 MHz
• AM Wave range: 522 -1611 kHz
• LW Wave range: 153 - 279 kHz
• Sensitivity at 75 Cl
mono, 26 dB signal-to-noise ratio: 1,2 pV
stereo, 46 dB signal-to-noise ratio: 45 pV
• Selectivity: 45 dB
• Total harmonic distortion: < 0,6 %
• Frequency response: 40 -15 000 Hz (± 3 dB)
• Signal-to-noise ratio: 72 dBA (mono)
CD player _
• Frequency range: 20 - 20 000 Hz
• Signal-to-noise ratio: 89 dB
• Dynamic range: 80 dB
• Channel separation: 80 dB
• Total harmonic distortion: 70 dB
• Conversion: Bitstream
Cassette deck
• Frequency range
Cr02 tape (type II): 100 -12 500 Hz (± 5 dB)
Normal tape (type I): 100 -12 500 Hz (± 5 dB)
• Signal-to-noise ratio (without Dolby NR)
Cr02 tape (type II): 53 dBA
Normal tape (type I): 51 dBA
• Wow and flutter: < 0,29% DIN
General
• Dimensions
Amplifier(wxhxd): 260x 115x312 mm
Tuner (wxhxd): 260x 57.5 x 254 mm
CD player (wxhx d): 260 x 57.5 x 254 mm
Cassette deck (wxhx d): 260 x 115 x 254 mm
Speakers (wxhx d): 172.5 x 345 x 254 mm
WARNING:
If the remedies fail to help, consult your dealer.
Under no circumstances should you repair any unit
yourself as this will invalidate the guarantee!
25
English
