Philips FW-C100/21 - Changing MW Tuning Grid

2-12
SPR 00 0015
1
English
Additional Features for /21/21M Preparations
AM ANTENNA
VOLTAGE
SELECTOR
110V- 127V 220V- 240V
AUX IN
R
+
–
L
–
+
AUDIO OUT
LR
AC
MAINS
~
FM AERIAL
75Ω
VOLTAGE
SELECTOR
110V- 127V 220V- 240V
VOLTAGE SELECTOR
220V- 240V 110V- 127V
A
B
E
C
D
F
Rear Connections
A
AM Loop Antenna Connection Connect the supplied loop antenna to the AM ANTENNA terminal. Place the AM loop antenna far away from the system and adjust its position for the best reception.
B
FM Wire Antenna Connection Connect the supplied FM wire antenna to the FM AERIAL (FM ANTENNA) 75 Ω terminal. Adjust the position of the FM antenna for the best reception. Outdoor Antenna For better FM stereo reception, connect an outdoor FM antenna to the FM AERIAL (FM ANTENNA) 75 Ω terminal using a 75 Ω coaxial wire.
FM ANTENNA 75Ω
FM AERIAL 75Ω
OR
D
Connecting other equipment to your player You can connect the audio left and right OUT terminals of a TV, VCR, Laser Disc player, DVD player or CD Recorder to the AUX IN terminals at the rear of the system.
E
Adjusting the Operating Voltage (For /21/ 21M versions only) Before connecting the AC power cord to the wall outlet, make sure that the voltage selector at the rear of the system is set to the local power line voltage. If not, reset the selector before connecting to the wall outlet.
F
AC Power Supply After all other connections have been made, connect the AC power cord to the system and to the wall outlet.
2
English
Tuner
Tuning to Preset Radio Stations
¶ Press 4 or 3 to select the desired preset
number. ➜ The preset number, radio frequency, and waveband appear on the display.
Changing the MW tuning grid
(For
/21/21M versions only) The frequency step can be changed if necessary. In North and South America, the frequency step between adjacent channels in the MW band is 10 kHz. In other parts of the world, it is 9 kHz. The frequency step preset in the factory is 9 KHz. For MW Band To change from 9 kHz to 10 kHz or vice versa Changing of tuning grid will erase all previously stored preset stations.
1
Disconnect the system from the AC power supply (pull out the AC power cord).
2
Press and hold TUNER and TUNING á while reconnecting the system to the AC power supply. ➜ Display will show “GRID 10” or “GRID 9”. Notes: – GRID 9 indicates that the tuning grid is in step of 9 kHz in MW band. GRID 10 indicates that the tuning grid is in step of 10 kHz in MW band. – FM tuning grid will also be changed from 50 kHz to 100 kHz or vice versa.
