Philips FW-C100/21 - Page 32

SPR 00 0029
6-8
ELECTRICAL PARTS LIST - FRONT BOARD
RESISTORS
4521 4822 051 20008 0R Jumper 0805
4522 4822 051 20008 0R Jumper 0805
4523 4822 051 20008 0R Jumper 0805
4524 4822 051 20008 0R Jumper 0805
4525 4822 051 20008 0R Jumper 0805
4526 4822 051 20008 0R Jumper 0805
4527 4822 051 20008 0R Jumper 0805
4528 4822 051 20008 0R Jumper 0805
4529 4822 051 20008 0R Jumper 0805
4530 4822 051 20008 0R Jumper 0805
4531 4822 051 20008 0R Jumper 0805
4532 4822 051 20008 0R Jumper 0805
4533 4822 051 20008 0R Jumper 0805
4534 4822 051 20008 0R Jumper 0805
4535 4822 051 20008 0R Jumper 0805
4536 4822 051 20008 0R Jumper 0805
4537 4822 051 20008 0R Jumper 0805
4538 4822 051 20008 0R Jumper 0805
4539 4822 051 20008 0R Jumper 0805
4540 4822 051 20008 0R Jumper 0805
4541 4822 051 20008 0R Jumper 0805
4542 4822 051 20008 0R Jumper 0805
4543 4822 051 20008 0R Jumper 0805
4544 4822 051 20008 0R Jumper 0805
4545 4822 051 20008 0R Jumper 0805
4546 4822 051 20008 0R Jumper 0805
4547 4822 051 20008 0R Jumper 0805
4588 4822 051 20008 0R Jumper 0805
4589 4822 051 20008 0R Jumper 0805
COILS & FILTERS
5400 4822 242 72066 Ceram Resonator 8MHz
5401 2422 543 01069 Crystal 32,768kHz
5402 4822 157 62552 Coil 2,2µH 5%
5404 4822 157 62552 Coil 2,2µH 5%
5405 4822 157 62552 Coil 2,2µH 5%
DIODES
6412 4822 130 30621 1N4148
6413 4822 130 30621 1N4148
6414 4822 130 30621 1N4148
6415 4822 130 30621 1N4148
6416 4822 130 30621 1N4148
6417 4822 130 30621 1N4148
6418 4822 130 30621 1N4148
6419 4822 130 30621 1N4148
6421 4822 130 30621 1N4148
6422 4822 130 30621 1N4148
6425 4822 130 31878 1N4003G
6426 4822 130 31878 1N4003G
TRANSISTORS & INTEGRATED CIRCUITS
7401 3139 110 52500 TMP87CP71F “C100S52501”
7402 9965 000 04931 M24C01-WMN6
7404 5322 209 11306 HEF4094BT
7408 5322 130 60159 BC847B
7409 4822 130 10165 GP1U28XP
7410 5322 130 60159 BC847B
7411 5322 130 60159 BC847B
7412 5322 130 60159 BC847B
7413 5322 130 60159 BC847B
Note: Only the parts mentioned in this list are normal
service spare parts.
